Wire-Rope Poly-house (turnkey/ customized greenhouse project)

Wire-Rope Poly-house (turnkey/ customized greenhouse project)

A wire rope polyhouse structure is a type of greenhouse structure that utilizes wire ropes or cable system as the primary support system at the top and usually poly-film or plastic- film are used as covering material.

Wire Rope Polyhouse

Meaning/Definition

A wire rope polyhouse structure is an innovative agricultural greenhouse specifically designed for agricultural purposes, especially for growing crops. Wire ropes are used as the main supporting structure, instead of traditional metal or wooden frames, forming the framework over which the poly-film cover is stretched.

Common/ Referred names

Low-cost Polyhouse, Wire Rope Flat Roof polyhouse, Polyhouse with cable support system, Polyhouse for vegetable farming, Polyhouse for floriculture, Polyhouse for horticulture, Polyhouse for fruit farming, Polyhouse for capsicum cultivation, Polyhouse for tomato cultivation, Polyhouse for cucumber cultivation, etc.

Technical Specifications

  • Wire ropes

    This polyhouse structure is typically made of Wire rope materials like stainless steel or galvanized steel, with different diameters that varies depending upon the requirements of the greenhouse.

  • Covering material

    The top covering material used for Wire rope Polyhouse is Poly-film which is commonly used as the covering material because they are cost-effective, permeable, and long-lasting.

  • Support system

    Wire rope polyhouses require a support system, also known as hockey, which are embedded to secure the structure firmly to the ground and provide mechanical support to prevent any movement or damage caused from strong winds.

Applications

  • Agriculture

    Wire rope polyhouses are primarily used for crop production, providing a controlled environment for growing fruits, vegetables, flowers, and other plants.

  • Horticulture

    These polyhouse structures are also used in horticulture for the cultivation of ornamental plants, nursery crops, and landscaping purposes.

  • Research

    Wire rope polyhouses can be utilized for research purposes in agricultural institutions, universities, and botanical gardens for studying plant physiology, crop breeding, and environmental impacts on plant growth.

Description

Product Type: Wire Rope poly-house
Top Vent Type: Flat Roof
Available Size: 500 m2 / 1000 m2 / 2000 m2 / 4000 m2 / 8000 m2 / 12000 m2
Grid: 8 m x 6 m
Side center/Height: 4.0 m / 4.0 m, 5.0 m / 5.0 m, 5.8 m / 5.8  m
Hockey: 2.5 m, 3.0 m, 3.5 m
Side Covering: Insect net, 110 GSM, Bird Net, Mono x Mono
Top Covering: 200 Micron Polyfilm, Shade Net for second Layer
Second Layer: Inside Sliding Net cover available
Trellising System: 5 mm, 4 mm Rope wire with 3 mm Plastic wire
Drip irrigation: Inline drip irrigation system, Fogging or Sprinkler with filters.
Usage/ application: Vegetable Farming (Capsicum, cucumber, chillies, tomato etc.), Horticulture, Flower farming, Herbs cultivation, nursery farming, etc.

Advantages

  • Cost-effectiveness

    Wire ropes are generally more affordable than traditional structural materials like metal or wood, making wire rope polyhouses a cost-effective option for greenhouse construction.

  • Lightweight

    Wire rope structures are lightweight yet sturdy, making them easy to assemble, transport, and install compared to heavier traditional structures.

  • Natural ventilation

    The open design of wire rope polyhouses facilitates natural ventilation, helping regulate temperature and humidity levels inside the greenhouse, which is crucial for optimal plant growth.

  • Flexibility

    The flexibility of wire ropes allows for customization of the greenhouse shape and size to suit specific growing needs and environmental conditions.

Conclusion

In summary, wire rope polyhouses offer a cost-effective, lightweight, and flexible solution for greenhouse construction, providing an ideal environment for plant growth while offering resistance to corrosion and facilitating natural ventilation.
