Wire Rope Flat Roof Shaded Net house (turnkey/ customized greenhouse structure)

Wire Rope Flat Roof Shaded Net house (turnkey/ customized greenhouse structure)

Meaning/Definition

An innovative and modern agricultural greenhouse structure, specially crafted to cater agricultural farming need and designed to provide shade and protection to crops is referred as wire rope flat roof shaded net house or Wire Rope Net house structure. It constitutes of a flat roof which is supported by a framework made of wire ropes, with a shade net covering the structure to shield the crops from over exposure to excessive sunlight while allowing controlled air circulation and light penetration. This shade net house structure is robust and sturdy that could combat and withstand any natural adversities to its maximum capacity. This structure can also be customized into Double Layer Shade Net House (Wire Rope Structure)

Common/ Referred names

This type of structure is commonly referred by as a low-cost shade net house, wire rope flat-roofed shade net house, wire rope net house, low-cost greenhouse, shade net house for tomatoes, shade net house for capsicum, shade net house for cucumber, shade net house chillies, shade net house for cabbage cultivation, green shade net house, shade net house for fruit farming, shade net house for red capsicum, shade net house for yellow capsicum, shade net house for vegetable farming, shade net house for fruit farming, shade net house for banana farming, shade net house for pomegranate, shade net house for papaya, Shade Net House for Vegetable Farming (50% Shading), Shade Net House with Cable Support System or simply a shaded net house.

Technical Specifications

  • Frame Material

    The framework of the wire rope shade net house is constructed using wire ropes made of durable materials such as galvanized steel or aluminum.

  • Optional Features

    Additional features such as roll-up side walls, insect-proof screens, and irrigation systems can be integrated into the net house design based on specific requirements.

  • Netting Material

    High-quality shade netting, typically made of nylon, is used to cover the frame, providing shade to crops while allowing ventilation and light transmission in this shade net house structure.

  • Roof Design

    The roof of the net house is flat, providing uniform coverage over the crops and allowing for easy installation of irrigation and shade systems.

  • Dimensions

    Wire rope flat roof shaded net houses come in various sizes, with widths and lengths customizable to fit specific agricultural needs and available space.

  • Anchoring

    Secure anchoring systems, such as ground stakes or concrete footings, are used to anchor the wire rope structure firmly to the ground, ensuring stability, especially in windy conditions.

Applications

  • Crop Cultivation

    These structures are suitable for cultivating a wide range of crops, including vegetables, fruits, flowers, and nursery stock, providing a controlled environment for healthy plant growth.

  • Nursery Operations

    Wire rope shaded net houses are ideal for seedling propagation and nursery operations, offering a protected environment for young plants to thrive.

  • Research and Education

    They serve as valuable tools for agricultural research institutions, universities, and educational facilities for studying crop production, pest management, and greenhouse technology.

Description

Product Type:

Wire Rope Shade Net house

Roof Type:

Flat Roof

Available Size:

500 m2 / 1000 m2 / 2000 m2 / 4000 m2 / 8000 m2 / 12000 m2

Grid:

8 m x 6 m

Side center/Height:

4.0 m / 4.0 m, 5.0 / 5.0 m, 5.8 m / 5.8 m

Hockey:

2.5 m, 3.0 m, 3.5 m

Side Covering:

Insect net, 110 GSM, Mono x Mono net, Bird Net

Top Covering:

Insect Net, Mono x Mono net 100 TO 125 GSM

Second Layer:

Inside Sliding Net cover available

Trellising System:

5 mm, 4 mm Rope wire with 3 mm Plastic wire

Drip irrigation:

Inline drip irrigation system, Fogging or Sprinkler with filters.

Usage/ application:

Vegetable Farming (Capsicum, cucumber, chillies, tomato etc.), Flower farming, Herbs cultivation, nursery farming, etc.

Advantages

  • Sun Protection

    Provides effective shade to crops, reducing heat stress and sunburn, leading to healthier plants and improved yield.

  • Temperature Regulation

    Maintains cooler temperatures inside the net house, creating a favorable environment for plant growth, especially during hot weather.

  • Natural Ventilation

    Allows for controlled airflow, preventing heat buildup and humidity levels, promoting healthy plant growth.

  • Pest and Bird Control

    Acts as a barrier against pests, insects, and birds, reducing crop damage and losses.

  • Year-Round Cultivation

    Enables year-round crop production, extending the growing season and maximizing yield potential.

  • Easy Installation and Maintenance

    Simple construction and maintenance requirements make wire rope shaded net houses easy to install and manage, reducing labor and operational costs.

  • Adaptability

    Can be customized to accommodate various crops and growing systems, offering flexibility to meet specific agricultural needs and preferences.

  • Cost-Effective

    Wire rope shaded net houses are relatively affordable compared to traditional greenhouse structures, making them accessible to small-scale farmers and growers.

Conclusion

In summary, wire rope flat roof shaded net houses offer effective sun protection, temperature regulation, natural ventilation, and pest control, making them valuable assets for crop production, nursery operations, and research in agriculture.
