Flat Roof Net House (pipe structure) (turnkey/ customized greenhouse structure)

Flat Roof Net House (pipe structure) (turnkey/ customized greenhouse structure)

Meaning/Definition

A modern agricultural greenhouse structure with flat roof that constitutes of GI pipes to form an innovative agricultural greenhouse structure that is specially designed to protect crops and allows controlled airflow and light penetration is known as Flat roof net house with a pipe structure. It consists of a framework made of pipes, usually PVC or galvanized steel, supporting a net covering that extends over the crops.

Common/ Referred names

This structure may also be known as a flat-roofed net house, pipe-structured net house, Shade net house for vegetable farming, nursery shade net house, shade net house for nursery, single layer shade net house, single layer flat roof shade net house, shade net house for tomatoes, shade net house for capsicum, shade net house for cucumber, shade net house chillies, shade net house for cabbage cultivation, green shade net house, shade net house for fruit farming, shade net house for red capsicum, shade net house for yellow capsicum, Shade Net House for Vegetable Farming (50% Shading)or simply a net house.

Technical Specifications

  • Frame Material

    Flat Roof Shade net house is constructed using GI pipes made from PVC or galvanized steel, providing structural support and stability to the net house.

  • Roof Design

    The roof of the shade net house is flat, providing uniform coverage over the crops and allowing for easy installation of irrigation and shade systems.

  • Netting Material

    High-quality Shade net, are made nylon, which is used to cover the entire pipe framework, providing protection against excessive sunlight but allowing adequate exposure to sun, and protecting against the threats of pests while allowing ventilation in the flat roof net house.

  • Dimensions

    Flat roof net houses come in various sizes, with widths and lengths customizable to fit specific agricultural needs and available space.

  • Optional Features

    Additional features such as roll-up side walls, insect-proof screens, and irrigation systems can be integrated into the net house design as per requirements.

  • Anchoring

    Secure anchoring systems, such as ground stakes or concrete footings, are used to anchor the structure firmly to the ground, ensuring stability, especially in windy conditions.

Applications

  • Crop Production

    Flat roof net houses are used to protect crops from pests, insects, birds, and adverse weather conditions such as heavy rain, hail, and wind.

  • Nursery Operations

    These structures are ideal for seedling propagation and nursery operations, providing a controlled environment for healthy plant growth.

  • Organic Farming

    Flat roof net houses support organic farming practices by reducing the need for chemical pesticides and promoting natural pest control methods.

  • Hydroponics and Vertical Farming

    They can be adapted for hydroponic and vertical farming systems, allowing for efficient use of space and resources.

  • Research and Education

    Flat roof net houses serve as valuable tools for agricultural research institutions, universities, and educational facilities for studying crop production, pest management, and greenhouse technology.

Description

Product Type: Flat Roof Shade Net house (Pipe Structure)
Roof Type: Flat Roof
Available Size: 500 m2 / 1000 m2 / 2000 m2 / 4000 m2 / 8000 m2 / 12000 m2
Grid: 6 m x 4 m (NHB guidelines), 6 m x 6m, 4 m x 4 m
Side center/Height: 4.0 m / 4.0 m, 5.0 / 5.0 m, 5.8 m / 5.8 m
Hockey: 2.0 m, 2.5 m, 3.0 m, 3.5 m
Side Covering: Insect net, 110 GSM, Mono x Mono net with Apron Sheet 140 GSM
Top Covering: Mono x Mono net 100 TO 125 GSM
Second Layer: Inside Sliding Net cover available
Trellising System: 5 mm, 4 mm Rope wire with 3 mm Plastic wire
Drip irrigation: Inline drip irrigation system, Fogging or Sprinkler with filters.
Usage/ application: Vegetable Farming (Capsicum, cucumber, chillies, tomato etc.), Flower farming, Herbs cultivation, nursery farming, etc.

Advantages

  • Crop Protection

    Provides effective protection against pests, insects, and birds, reducing crop damage and losses.

  • Weather Resistance

    Offers shelter from adverse weather conditions, maintaining stable growing conditions and protecting crops from wind, rain, and hail.

  • Improved Ventilation

    Allows for controlled airflow, preventing heat buildup and humidity levels, promoting healthy plant growth.

  • Natural Pest Control

    Reduces the need for chemical pesticides, promoting environmentally friendly pest management practices.

  • Year-Round Cultivation

    Enables year-round crop production, extending the growing season and maximizing yield potential.

  • Easy Installation and Maintenance

    Simple construction and maintenance requirements make flat roof net houses easy to install and manage, reducing labor and operational costs.

  • Adaptability

    Can be customized to accommodate various crops and growing systems, offering flexibility to meet specific agricultural needs and preferences.

  • Cost-Effective

    Flat roof net houses are relatively affordable compared to traditional greenhouse structures, making them accessible to small-scale farmers and growers.

Conclusion

In summary, flat roof net houses with pipe structures offer effective crop protection, weather resistance, improved ventilation, and natural pest control, making them valuable assets for crop production, nursery operations, and research in agriculture.
